Planning approval granted for final key West Midlands structures bringing HS2 into Birmingham

The final two major structures being built to bring HS2 into Birmingham have been approved by local councils - marking another significant milestone for the project. Approval has been granted for the design of two new viaducts, meaning eight “Key Design Elements” (KDEs) on the West Midlands section of the route have now passed the Schedule 17 process.

KDEs are structures on the HS2 project identified as being significant because of their size, proximity to communities, or location within sensitive areas. Because of these challenges, HS2 has undertaken extensive engagement with local communities to listen to people’s views and incorporate feedback in the design of the structures where possible.

The River Blythe Viaduct has received Schedule 17 planning approval from Solihull Metropolitan Borough Council. A 475-metre low-lying structure, just south of the new HS2 Interchange Station in Solihull, it is designed to skim the flat, agricultural landscape as it crosses the River Blythe, the floodplain and Meriden Road near Hampton in Arden. Feedback from the local community has been incorporated into the planning of the construction of this viaduct, particularly regarding tree planting and protecting the local environment in the areas near the river which are designated as a Site of Special Scientific Interest.

Saltley Viaduct has received planning approval from Birmingham City Council. It is a 225-metre structure, including approaches, located two miles north-east of Birmingham city centre, and will take the B4144 road over the HS2 line, the Birmingham and Warwick Junction Canal, the Birmingham and Derby rail line and the River Rea. It will be an important crossing point, providing access to the city centre and the wards of Nechells and Alum Rock.

A wider pathway to make room for cyclists, additional lighting, and replacing stainless steel material with weathering steel panels and a perforated pattern, were key requirements from local people, which have all been incorporated.

One other KDE in Birmingham is Aston Church Road Overbridge: Located two miles north-east of Birmingham city centre, it will take Aston Church Road over the HS2 line to connect Saltley, Washwood Heath and Nechells in Birmingham. The new alignment of Aston Church Road with the creation of safe pedestrian crossing points has provided an opportunity to provide a new public space in front of the local Mosque.

One other KDE in Solihull is Balsall Common Viaduct: A 425 metre viaduct just outside the built-up part of Balsall Common, on the north-eastern side of the existing Network Rail line, crossing over Station Road, Bayleys Brook, Heart of England Way Walk and the associated floodplain. The Kenilworth Greenway will be extended to Station Road on the south-eastern side of the existing railway line and options for cycling and bridleway extensions are also being considered.

Four other KDEs in North Warwickshire are:

- Burton Green ‘Green Tunnel’: A 700 metre green tunnel, which will have green space created over the top covered with trees and plants to reconnect the Kenilworth Greenway and provide a new landscape for the local community. Enhanced environmental features include extensive tree planting, new footpaths and better connections to local woods. The northern end of the structure, where the railway exits the tunnel in a cutting, is in Solihull.
- Water Orton Viaducts: Two 700 metre viaducts located east of the M42 and Lichfield Road, taking trains over the River Tame and the Birmingham to Peterborough train line between Water Orton and Coleshill Parkway Stations. Designs include feedback from the community including a more connected and accessible area with tree planting and new wildlife habitats with an opportunity, subject to local interest, for a community orchard or area of allotments.
- River Cole Viaducts: Two parallel 158-metre viaducts over the River Cole in North Warwickshire, on the western part of the Delta Junction taking trains between London and Birmingham. Extensive new landscape and wildlife areas inspired by local heritage will be created around the viaducts, while new footpaths and cycleways will promote active travel and enable people to explore the rich history of the area.
- Chattle Hill Structure: Located in the north east corner of the Delta Junction, taking the HS2 line over the A446 Lichfield Road, on the section of railway taking trains direct between London and the North. There are plans for a ‘blossom walk’ to link to a new community orchard and allotment areas, along with the planting of fruit trees and herbs for foraging.

These KDE structures form part of the section being designed and built by Balfour Beatty VINCI, HS2’s construction partner in the Midlands, together with a Design Joint Venture of Mott MacDonald and SYSTRA with Weston Williamson + Partners as architects. This project team is responsible for delivering the 90km stretch of the route spanning from Long Itchington in Warwickshire to the centre of Birmingham and on to Handsacre in Staffordshire. A workforce of over 9,000 people and 400 companies in the West Midlands are helping to build HS2.

In total BBV are building 42 viaducts (totalling 11 km), 62 overbridges, 62 embankments, 34 cuttings, 28 underbridges, 11 underpasses, along with two twin bore tunnels and two cut and cover tunnels (totalling 15 km).
